New Testing Technology at IDT: Detailed and Extensive
We have consistently expanded our testing technology—with advanced lab equipment, a new measuring room, and processes that ensure more quality, reliability, and transparency in every step of the process. Our expanded lab and testing technology show our commitment: producing gaskets and proving their quality.
Modern Testing Technology for the Highest Requirements
Measuring room for depth of detail
In our new measuring room, we test what others cannot measure – down to the last detail. This provides additional certainty in every test report and reliability for products that must meet the highest requirements.
CNC measurement for complex geometries
Complex geometries are captured in seconds with our CNC image measuring device. Testing procedures are automated and deliver repeatable, reliable results. This allows us to gain speed and significantly increase the number of tested features.
3D measurement with Hexagon measuring arm
With the mobile Hexagon 3D measuring arm, we capture entire surfaces using laser scanning. Particularly complex gaskets, such as butterfly valve seals, can now be digitized in their entirety for the first time and evaluated using comparative models. This creates transparency in quality assurance and makes technical discussions more reliable.
Advanced methods. From TA Luft to thermogravimetry
Our testing technology goes far beyond geometric measurement: from TA Luft test benches to thermogravimetric analyses (TGA) to material analyses with spectrometers, we offer a broad testing portfolio in accordance with international standards.
For us, quality means more than just dimensional accuracy—it is deeply rooted in our corporate culture. With our new testing technology, we can now capture characteristics that were previously not measurable, such as complex geometries or position tolerances. This has a double benefit: we ensure consistently high quality in series production for our customers and create full transparency with detailed test reports.
Your Added Value
Process reliability through tighter inspection lots
We can set tighter inspection lots and detect deviations more quickly. This means stable processes across the entire series.
Traceability with detailed test reports
Our test reports are more comprehensive and more detailed than before – an important basis for traceability and quality assurance.
Rapid feedback in the event of deviations
Automated processes enable us to detect deviations immediately. Customers benefit from clear feedback and rapid response.
Sustainability through efficient testing processes
Less rework, less waste: our testing methods directly contribute to resource conservation while meeting the highest quality standards.
FAQ about seal testing at IDT #
We test gaskets using advanced testing technology – from CNC image measuring devices and climate-controlled measuring rooms to mobile 3D measuring arms. This enables us to record complex geometries, shape and position tolerances, position deviations, and radii precisely and repeatably.
We offer a wide range:
- Leak tests in accordance with DIN EN 13555, DIN 28090, VDI 2440, and others
- Compression, creep, and relaxation tests
- TA Luft tests for emission verification
- Thermogravimetry (TGA) for material analysis
- 3D measurements using laser scanning technology
Our tests are based on common standards such as DIN EN 13555, DIN 28090-1/2, DIN 3535, DIN 52913, VDI 2440/2200, and DIN EN ISO 15848-1. Individual tests according to specific requirements are also possible.
Yes. With our Hexagon 3D measuring arm, we can, for example, digitize butterfly valve seals over their entire surface for the first time. This creates evaluable comparison models that provide clarity even with challenging geometries.
- More tested features per part
- Faster feedback in case of deviations
- Tighter inspection lots for genuine process monitoring
- Complete documentation and traceability
- Consistent quality from initial sample to series production
Yes. We perform tests not only for our own products, but also as a service for our customers. This allows you to benefit from advanced measurement technology without having to invest in it yourself.
The costs depend on the test procedure, the standard, and the complexity of the gasket. We would be happy to provide you with a customized quote.
Precise testing helps to avoid rejects and rework. In addition, TA-Luft-compliant testing enables the safe reduction of emissions – an important contribution to sustainable processes.
More about quality assurance at IDT
Details about our testing technology and our understanding of quality can be found in our flyer.
